Enhance Your Raspberry Pi with the RS485 CAN HAT (B)
Elevate your Raspberry Pi projects with the RS485 CAN HAT (B). This versatile HAT brings robust RS485 and CAN communication capabilities to your Raspberry Pi, providing isolated and stable connections. It features a standard 40-pin GPIO header, making it compatible with the entire Raspberry Pi series.
Experience seamless communication with 1-Ch CAN and 2-Ch RS485. The built-in MCP2515 controller and CAN transceiver convert SPI to CAN, while the SC16IS752 and SP3485 chip combination convert SPI to RS485. Designed for industrial-grade performance, it includes onboard power supply isolation and digital isolation, ensuring reliable, jam-proof signals with low power consumption.
With an onboard power conversion circuit supporting an 8-28V wide voltage range, it can also power your Raspberry Pi simultaneously. Protection features include TVS for surge voltage, a resettable fuse, and protection diodes, guaranteeing stable output and enhanced resistance to shocks and static. Your Raspberry Pi projects have never been this powerful and resilient.
Discover the capabilities of the Waveshare Isolated RS485 CAN HAT for your Raspberry Pi, designed to expand and stabilize RS485 and CAN communication. Easily integrate this HAT with any Raspberry Pi using its standard 40PIN GPIO extension header.
Features:
Connectivity Technology: Utilizes GPIO for seamless integration with Raspberry Pi models including 4B, 3B+, 3B, 2B, Zero, Zero W, and Zero 2W/2WH. Communication Channels: Provides 1-Ch CAN using the MCP2515 controller to convert SPI to CAN, and 2-Ch RS485 using a dual-chip SC16IS752+SP3485 combination to convert SPI to RS485. Isolation Protection: Features industrial-grade isolation with built-in power supply isolation, ensuring stable voltage without needing extra power supply for the isolated channels. Voltage Support: Comes with an 8~28V wide voltage power supply that can also power the Raspberry Pi, enhancing versatility and convenience. Surge Protection: Includes onboard TVS (Transient Voltage Suppressor) to suppress surge and transient spike voltages, making the module lightning-proof and anti-electrostatic. Additional Safety: Equipped with resettable fuses and protection diodes that ensure stable current/voltage outputs and provide over-current/over-voltage protection, enhancing the shock resistance.
Elevate your Raspberry Pi projects with the Waveshare RS485 CAN HAT. It brings reliable, isolated communication capabilities essential for industrial and DIY applications.
